AR 258 AAronia HF-8000 Compatible Battery 3.7V 8500mAh

AAronia HF-8000 / SPECTRAN V5 — 3.7V Li-Polymer Replacement Battery (AR 258)

This 3.7V, 8500mAh lithium-polymer pack replaces the OEM AR 258 battery in the AAronia HF-8000 and SPECTRAN V5 RF measurement instruments. Both devices run the same voltage rail and use a compatible connector and BMS handshake, so one pack covers either platform. At 31.45Wh, it gives field technicians meaningful capacity headroom during extended RF survey sessions.

• HF-8000 and SPECTRAN V5 compatibility: Both instruments share the same 3.7V supply rail, physical form factor, and BMS communication protocol. The AR 258 spec covers both — no adapter or modification needed.
• Bench tested on actual hardware: We cycled this pack through sustained sensor-active logging loads and monitored BMS cutoff thresholds. The protection circuit held stable under the probe initialisation current spike that causes issues with weaker aftermarket cells.
• Post-install calibration on the HF-8000: After fitting this pack, run a full calibration cycle through the instrument menu before your first field deployment. The HF-8000 maps battery state during calibration — skipping this step causes premature low-battery warnings during the first measurement session, even with a full charge.

BMS lockout after the HF-8000 sat unused in a carry case for months

Li-polymer cells self-discharge slowly during storage. If the HF-8000 sat unused long enough, the cell voltage can drop below the BMS recovery threshold — typically around 2.5V per cell — and the protection circuit latches into lockout. The instrument then shows no power or no charge activity when you plug it in. To recover, connect the charger and leave it undisturbed for 30–60 minutes; most protection circuits will exit sleep mode once the charger applies a trickle current and cell voltage climbs back above 2.8V.

Readings drifting or logging session resetting mid-survey

This happens when sustained sensor load causes a voltage dropout that briefly dips below the instrument's operating floor. The HF-8000 draws more current during active antenna scanning and data logging than during standby, and an aged or partially discharged cell may not hold voltage under that load. The result is a mid-session reset or corrupted log file — not a full shutdown. Charge the pack to 100% before the session and check that resting voltage reads at least 4.1V before deployment.
