Streamlight Dualie — 3.7V Li-ion Replacement Battery (68792)

This is a 3.7V, 2200mAh lithium-ion battery for the Streamlight Dualie flashlight. It replaces OEM part 68792 and restores full output to the Dualie's dual-beam driver circuit. Capacity figures come from product data, not estimated specs.

• Dualie platform fit: The Dualie uses a single-cell 3.7V Li-ion format tied directly to its dual-beam driver. Voltage must match the driver's input range — substituting a different chemistry or nominal voltage causes the driver to step down output immediately or refuse to switch modes.
• Bench tested on actual hardware: We cycled this cell through the Dualie's low, medium, and turbo output modes. The BMS held cutoff at the expected low-voltage threshold without tripping prematurely under the current spikes turbo mode pulls.
• Turbo mode draw management: Turbo mode on the Dualie pulls significantly more current than low or medium. Avoid leaving the light locked in turbo during long stationary use — heat builds in the cell body, accelerating capacity fade over repeated cycles. Step down to medium when maximum output is not needed.

Why the Dualie steps down output before the battery indicator signals low

The Dualie's driver monitors cell voltage continuously and begins reducing output once voltage drops below its brownout threshold — typically around 3.0V under load. This happens before any low-battery indicator fires because the indicator reads resting voltage, not the loaded voltage the driver sees mid-draw. At turbo current levels, the loaded voltage can sag 0.2–0.4V below resting, triggering a step-down that looks like premature dimming. Switching to medium mode reduces the sag and extends usable output before the cell actually needs charging.

Cell reads charged but turbo mode cuts out within seconds of activation

This happens when an aged or deeply discharged cell can no longer sustain the current turbo mode demands, even if resting voltage looks healthy. The BMS detects the voltage collapse under high draw and trips the protection circuit to prevent cell damage. Charge the battery fully, then check resting voltage with a multimeter — a healthy cell should read 4.1–4.2V fully charged. If resting voltage sits below 3.8V after a full charge cycle, the cell has lost capacity and needs replacement.
