Casio HA-G20BAT DT-X30 Replacement Battery 7.4V 2600mAh

Casio DT-X30 Series — 7.4V Li-ion Replacement Battery (HA-G20BAT)

This is a 7.4V, 2600mAh Li-ion replacement for the Casio HA-G20BAT battery pack. It fits the DT-X30, DT-X30G, DT-X30GR-30C, and IT-9000 handheld barcode scanners — devices used heavily in warehouse pick-and-pack, retail stocktake, and logistics operations. Capacity is 2600mAh (19.24Wh), matching the original specification.

• DT-X30 and IT-9000 compatibility: These models share the same 7.4V battery bay, connector pin-out, and BMS handshake protocol. One pack fits all four without adapter or modification.
• Bench tested on actual hardware: We ran this pack through charge, discharge, and scan-burst cycles on a DT-X30 unit. The BMS negotiated correctly with the scanner's charge controller, and cell voltage held steady across repeated laser trigger events.
• First-shift preparation: After installing the pack, seat it in the charging cradle for a full cycle before putting the scanner on the floor. Scan-trigger inrush current is highest when the cell is near minimum charge. A fully charged cell prevents the BMS from tripping on the first burst of rapid scanning.

Cradle showing a charging error on a new pack

Charging errors on a fresh pack are almost always a contact resistance issue, not a BMS fault. The DT-X30 cradle uses spring-loaded dock contacts that oxidise with repeated insertions. Oxidisation raises resistance enough that the cradle reports a fault before current even flows. Remove the pack, wipe the gold contacts on both the battery and the cradle with a dry cloth, reseat firmly, and check that all four contact pins are making full engagement.

Scanner losing wireless connection during rapid scan bursts

The DT-X30 pulls current from two sources simultaneously during rapid scanning — the wireless radio polling the host and the laser or imager firing on each trigger pull. When a degraded or partially charged battery can't sustain both loads, voltage sags briefly and the radio stack drops its connection. This is not a Wi-Fi signal issue — it's a combined inrush problem. Charge the pack fully before use and check cell voltage under load; a healthy cell should hold above 6.8V during a burst cycle.
