36V Honda Lawn Mower Replacement Battery 5000mAh Li-ion

Up to 14% off
New arrival
Sale priceFrom $190.99 USD Regular price $222.99
Shipping calculated at checkout.
Replaces Honda DP3660XA lawn mower and handheld tool batteries across their universal cordless system.
36V 5.0Ah lithium-ion delivers sustained power for deck cutting and trimming without mid-task sag.
Connector orientation and locking tab match Honda's original slot design for single-direction install.
We cycled this pack under load on a mower deck; BMS held stable across full discharge.
Charge on Honda's standard 36V charger; Thermo Smart technology regulates cell temperature during first charge.
Extended delivery time

⚠️ This item is available by SPECIAL ORDER. Delivery for this product typically takes 2–3 weeks.

Extra Discount: As a thank you for your patience, enjoy an extra 5% off your order
EXTRAOFF

Visa Mastercard American Express PayPal Apple Pay Google Pay Shop Pay Discover Klarna Afterpay Stripe

Check that your old battery model number and device model to match our description. This makes sure they work together.


We ship your order same day if you buy it before 4 PM EST.

Warranty

Send Your Battery Photo

Expert Technician Help

Snap a photo or video of your battery and send it to us. We'll identify the exact replacement—fast and hassle-free. Our team has helped thousands of customers find the right battery quickly and easily.

POST YOUR BATTERY IMAGE
Product & Solutions Expert

Product & Solutions Expert

✉ sales@batteryweb.com

🔹 10+ Years Battery Experience 🔹 Fast & Accurate Identification

Battery Care Tips

🔹 Getting Started

Charge your new battery fully before you use it for the first time. Over the next few charge cycles, run your device down to around 20% before you recharge—this helps the battery perform its best. After that, charge whenever you need to.

🔹 Keep It Healthy

Avoid letting your battery completely drain or staying plugged in constantly. Both extremes wear it out faster. Store the battery in a cool, dry place when you're not using it, since heat damages batteries quickly.

Delivery and Shipping

🔹 Most orders ship the next day, and we use FedEx, UPS, Purolator and other carriers to get them to you. Lithium batteries have to ship by ground only, not air or USPS. Make sure your address is right before you order, because if we have to send it back, you pay for shipping again.

Disclaimer

⚠️ Disclaimer: All product names, trademarks, and registered trademarks belong to their respective owners.

🔹 We use these names, brands, or model numbers only for identification and compatibility purposes.


Voltage

36V

Amp

5000mAh

Honda Universal Cordless System — 36V Li-ion Replacement Battery

This 36V 5000mAh lithium-ion pack replaces Honda part numbers 1026548, DPW3690XA, DP3660XA, and DP3640XA. It fits Honda's Universal Cordless System lineup, including the HRX 476 XB VE lawnmower and HHH 36 AXB hedge trimmer. Voltage matches the 36V rail these tools run on; capacity comes in at 5000mAh and 180Wh.

  • Shared platform compatibility: Honda's Universal Cordless System uses the same 36V connector and BMS handshake across handheld tools and lawnmowers, so one battery shell covers the full range of compatible models.
  • Bench tested on actual hardware: We ran full charge/discharge cycles — the BMS held voltage steady under load and triggered the low-voltage cutoff cleanly without thermal events.
  • First charge on a new pack: Run a full charge before the first use on your lawnmower or trimmer — lithium-ion cells perform more consistently once the BMS completes its first full calibration cycle.

Why the 36V rail matters for Honda cordless lawnmowers

Honda's HRX and cordless handheld range runs a 36V architecture because it balances motor torque demand with cell count. Dropping below 36V nominal causes the tool's BMS to cut power early as a protection measure. A correctly rated replacement pack keeps the voltage window within spec, so the motor draws current at the intended rate across the full discharge curve.

Battery not recognised by the charger — what's happening and how to fix it

If the Honda charger flashes an error on a new pack, the cells are likely too cold or the BMS hasn't been initialised. Li-ion packs below 10°C can trigger a charger lockout as a safety measure. Bring the battery to room temperature, wait 20 minutes, then reconnect. If the fault persists, briefly seat the pack in the tool and press the trigger — this can wake a deeply discharged BMS before returning it to the charger.

Compatible Models

DP3660XA HRX 476 XB VE HHH 36 AXB HHH36AXB HRG 466 XB SE HRG 466 XB

Replaces Part Numbers

1026548 DPW3690XA DP3660XA DP3640XA

Technical Specifications

Voltage36V
Amp Hours5000mAh
Capacity5000mAh
Rate180Wh
Net Weight1256g /44.30 oz
Gross Weight1446g /51.01 oz
Approximate Weight1446g /51.01 oz
Dimension 158.00 x 97.50 x 74.00mm

Product Highlights

  • Brand: Honda
  • Manufacturer: CS
  • Series: Standard
  • Color: Black/Red
  • Product Type: Li-ion
  • Battery Type: Li-ion
  • Warranty: 12 Months
  • Bulk Orders: sales@batteryweb.com

Frequently Asked Questions

My Honda cordless mower starts fine then bogs down halfway through the lawn — is that the battery dying or something else?

That mid-session power drop on a 36V mower is almost always voltage sag under load, not a dead battery — the pack still has charge but can't sustain current draw when the deck hits thick grass. Check the battery's indicator LEDs immediately after it bogs: if you see two or more lights still on, the cells are present but the pack is struggling to hold voltage under sustained draw. A replacement pack with fresh high-drain cells will hold the rail voltage steadier through the full cut. To confirm it's the battery and not the motor, run the blower or trimmer on the same pack — if those tools run fine, the mower's load is simply exposing a weak cell group.

Honda battery clicked off mid-use and now it won't power on at all — not even the charge indicator shows anything

The Thermo Smart system in this pack is designed to shut the battery down completely if internal temperature hits a threshold — and after a full shutdown it can enter a protection-locked state that looks identical to a dead battery. Let the pack sit in a cool, shaded spot for 20 minutes, then press the indicator button: if zero LEDs respond, the BMS is still latched in protection mode. Try seating it on the charger anyway — a compatible Honda charger can sometimes reset the protection circuit through the charge handshake even when the pack won't respond standalone. If the charger shows a fault code or alternating LED pattern rather than a solid charge indicator, the protection trip was likely a cell-level event and the pack needs replacing.

Replaced the battery on my Honda HRX mower and now the charger just blinks and never goes to solid green

A blinking charge light that never settles means the charger is seeing the battery but rejecting the handshake — the most common cause with aftermarket or replacement packs is a cell voltage that's landed below the charger's recovery threshold after sitting discharged too long. Check whether the battery's own indicator shows any LEDs at all before you put it on charge; if it shows one flashing LED, the pack has dropped into deep-discharge territory. Some Honda chargers will not initiate a full charge cycle on a pack sitting below roughly 25V — try a brief jump-start using a compatible tool to draw a small load and then immediately re-seat it on the charger. If the blink pattern stays irregular after two attempts, log the exact LED sequence, as Honda charger codes differ between a bad pack, a temperature block, and a communication fault.
