Signode BXT2 / VT550L — 14.4V Li-ion Replacement Battery

This 14.4V, 4000mAh Li-ion battery fits the Signode BXT2 and VT550L electric strapping tools. These are battery-powered cordless strappers used in warehousing, logistics, and shipping environments to tension and seal plastic or steel strapping on packages and pallets. Swap a depleted pack and keep the line moving without waiting on a corded setup.

• BXT2 and VT550L compatibility: Both tools run on the same 14.4V rail and share an identical battery housing with the same connector orientation and BMS handshake protocol — one battery serves either tool on the floor.
• Bench tested on actual hardware: We cycled this pack through full tensioning sequences on the BXT2 and monitored the BMS under peak motor draw at maximum tension. Cell voltages stayed balanced across the full discharge curve and the protection circuit held without false cutoffs.
• Cold warehouse use: If the tool is stored or staged in a cold loading dock below 10°C, bring the battery to room temperature before starting a tensioning run. A cold cell hits a sharp internal resistance spike during the motor's peak draw, which the BMS reads as an overcurrent event and shuts the pack down mid-cycle.

BMS cutoff during the tensioning cycle on the BXT2

The BXT2 motor draws a sharp current spike right at the final tensioning stage when strap load is highest. If the battery's state of charge is below roughly 20%, the cell voltage dips fast enough under that load for the BMS to trigger an overcurrent cutoff — the tool stops mid-tension. This is not a faulty battery; it is the protection circuit doing its job on a low cell. Recharge to full before starting a fresh strapping run if the tool has been in continuous use.

Charger fault light on a new pack that's been sitting in storage

Li-ion cells that have sat unused for several months can drop below the charger's minimum acceptance voltage — typically around 10V for a 14.4V pack. The Signode charger reads that as a fault and refuses to begin a charge cycle. Most chargers have a recovery or trickle mode; activate it to bring the cells back up to the acceptance threshold before switching to normal charge. If the charger has no recovery mode, a bench power supply set to 12V at 0.5A for 10–15 minutes is enough to raise the pack voltage above the acceptance floor so the charger will recognise and accept it.
