BenQ JoyBook R56 11.1V Replacement Battery 2C.20770.001

BenQ JoyBook R56 / R42 / C41 Series — 11.1V Li-ion Replacement Battery (2C.20770.001)

This 11.1V 4400mAh Li-ion battery replaces the original cell in the BenQ JoyBook R56, R42, C41, and C41E notebooks, along with over 28 additional JoyBook models. It matches the OEM voltage, capacity, and connector pinout exactly. Cross-references include SQU-701, SQU-712, SQU-714, 916C5820F, 916C5840F, and DHR504, among others.

• JoyBook R56 / R42 / C41 platform compatibility: These JoyBook models share the same 11.1V three-cell battery rail, identical connector housing, and a compatible BMS handshake protocol — which is why a single cell covers all of them without modification.
• Bench tested on actual hardware: We cycled this cell through charge and discharge on a JoyBook R56 chassis. The BMS negotiated charge termination correctly at full voltage, and the protection circuit tripped as expected at the low-voltage cutoff threshold — no false trips under normal load.
• First-install calibration on the JoyBook platform: After fitting, run the notebook down to automatic hibernate cutoff, then charge uninterrupted to 100% with the lid open. This forces the JoyBook's fuel gauge IC to reset its learned capacity data against the new cell and clears the inaccurate health warning that appears after every cell swap.

Why the JoyBook R56 shuts down at 20–30% shown on the gauge

This happens when the ageing original cell can no longer sustain voltage under combined CPU and display load — the actual cell voltage collapses below the BMS cutoff threshold before the fuel gauge reaches zero. The gauge reports percentage based on stored EEPROM data calibrated to the old cell's degraded capacity, so the numbers no longer reflect reality. After swapping to a new cell, the same symptom can persist for two or three cycles until the fuel gauge IC recalibrates. Run two full discharge-to-hibernate and uninterrupted charge cycles to re-anchor the gauge to the new cell's actual voltage curve.

BIOS reporting battery health as poor or unknown after fitting a new cell

The JoyBook BIOS reads health status from EEPROM data embedded in the battery's BMS circuit — it does not measure cell condition directly. When a new cell is installed, the EEPROM cycle count and rated Wh data differ from what the BIOS previously logged, triggering a "poor health" or "unknown" flag. This is a data-mismatch warning, not a fault with the replacement cell. Complete one full battery learn cycle — discharge to hibernate cutoff, then charge uninterrupted to 100% — and the BIOS health status will update to reflect the new cell correctly.
