Deviser DS2500S — 7.4V Li-ion Replacement Battery (B203G001)

This is a 7.4V 7800mAh (57.72Wh) Li-ion replacement battery for the Deviser DS2500S surveying instrument. It replaces OEM part B203G001 and restores full operating power to the DS2500S in the field. The cell chemistry and BMS protection profile match the original pack's voltage rails and charge termination behaviour.

• DS2500S platform compatibility: The DS2500S uses a fixed connector and BMS handshake tied to the B203G001 spec. This pack runs the same 7.4V nominal rail and matches the charge termination voltage the instrument expects. Swapping in a pack with different cutoff thresholds causes the instrument to flag a battery fault or refuse to power on.
• Bench tested on actual hardware: We ran this pack through the DS2500S power-on sequence, probe initialisation draw, and a sustained logging load. The BMS held stable through the initialisation current spike and did not trip under continuous sensor load at the rated voltage.
• First-use calibration cycle: After installing this pack, run a full calibration cycle through the DS2500S instrument menu before heading into the field. The instrument maps battery state during calibration. Skipping this step causes premature low-battery warnings during the first measurement session even when the pack is fully charged.

BMS trip at probe or sensor initialisation on the DS2500S

When the DS2500S powers up a connected probe or sensor module, the initialisation sequence draws a short but sharp current spike. If the battery BMS has a low overcurrent threshold — common in aged or counterfeit packs — it trips at that spike and the instrument cuts out instantly. The B203G001 spec sets the overcurrent threshold above the probe initialisation peak, so the BMS stays latched through startup. If the instrument cuts out specifically at probe power-up, check the battery voltage first — a cell below 6.8V will trigger this even on a healthy BMS.

DS2500S shuts down mid-logging session with no low-battery warning

This happens when sustained sensor load pulls the pack voltage below the instrument's undervoltage cutoff before the battery indicator has updated. The display may still show two or three bars when the shutdown occurs. It is a voltage sag issue, not a capacity issue — a degraded cell with high internal resistance drops voltage under load even if it reads fine at rest. To confirm, check the resting voltage with a multimeter after a shutdown; a healthy cell should read above 7.0V at rest. If the resting voltage is above 7.0V but the instrument still cuts out under load, the pack's internal resistance has risen past the point where it can sustain the DS2500S sensor current draw.
