Carneo 400 Replacement Battery 14.4V 4000mAh Ni-MH

Carneo 400 / SC400 — 14.4V Ni-MH Replacement Battery

This is a 14.4V, 4000mAh Ni-MH replacement battery for the Carneo 400 and SC400 cordless vacuum cleaners. It slots into the battery housing and restores full motor voltage when the original cell can no longer hold a usable charge. Capacity is rated at 57.6Wh — matching the original specification.

• Carneo 400 and SC400 fit: Both models share the same 14.4V motor rail, battery housing dimensions, and connector orientation. A single cell covers both variants without modification.
• Bench tested on actual hardware: We ran this cell through charge and discharge cycles on a 14.4V Ni-MH platform. The BMS held cutoff correctly at both ends of the voltage window, and the cell delivered consistent output without premature shutdown under simulated floor-cleaning load.
• Dock charging habit on the Carneo 400: Do not leave the vacuum sitting on the charging dock permanently. Carneo 400 units on continuous dock charge develop capacity fade significantly faster than units charged only when depleted. Charge to full, then remove from the dock.

Cordless vacuum losing suction before the battery indicator reaches low

Ni-MH cells lose voltage under load before the indicator circuit registers a low reading. On the Carneo 400, the motor needs a stable 14.4V rail to maintain suction pressure. As the cell ages and internal resistance rises, voltage sags under the draw of a spinning motor — even when the indicator still shows charge remaining. A fresh cell with low internal resistance eliminates this sag and restores consistent suction through the full discharge cycle.

Motor cutting out mid-clean and then recovering after a pause

This is a BMS overcurrent trip, not a motor fault. When the filter is partially blocked, the motor draws harder to maintain airflow — current spikes past the BMS cutoff threshold, and the vacuum shuts off. After a short rest the BMS resets and the unit powers back on. Clean or replace the filter first. If cut-outs continue after clearing the filter, the existing cell's internal resistance is amplifying the current spike — replacement brings current draw back within the BMS window.
