360 S6 Pro Replacement Battery 14.4V 5200mAh D080-4S2P

Up to 19% off
New arrival
From $81.99 USD $100.99
Shipping calculated at checkout.
Fits 360 S6 Pro, S9, X90, X95 cordless vacuums; replaces OEM part D080-4S2P.
14.4V, 5200mAh lithium-ion delivers 74.88Wh to restore full motor power and suction.
Connector slides into battery slot with locking tab on left side; keyed fit prevents reverse insertion.
Bench test showed clean BMS handshake on first insertion; pack held voltage stable under sustained motor draw.
Do not leave this battery on the charging dock continuously — trickle charge degrades capacity faster than charge-and-remove cycles.
Visa Mastercard American Express PayPal Apple Pay Google Pay Shop Pay Discover Klarna Afterpay Stripe
✦

Check that your old battery model number and device model to match our description. This makes sure they work together.

✦

We ship your order same day if you buy it before 4 PM EST.

Warranty

Let customers speak for us

from 11 reviews

Product is exactly as described and arrived quickly

Robert Jones
Rocket ES4-12 Compatible Replacement Battery

It took a bit longer than expected, likely due to the holiday season, but that was understandable. So far, the battery seems to be working well!

Linda M.
MGE UPS Systems Pulsar EX 1500RT Compatible Replacement Battery By Bright Way

Excellent substitute for the original, appearing to be the perfect replacement.

Alberto J.
APC SMART-UPS RT SURTA3000RMXL3U UPS High Performance Replacement Battery Set

It was what i was looking for. Support is fast

Jaswal
WAHEGURUG - RADHASWAMI

Fast service

Mark Casias
BatteryWeb

Perfect fit

Mark Casias
STX20L-BS Battery for Harley Softail FLS FLST 1991-2017 High Performance

Works Perfectly!!

Ben Benson
Invacare 220 Scooter High Performance Medical Replacement Battery Set

Send Your Battery Photo

Expert Technician Help

Snap a photo or video of your battery and send it to us. We'll identify the exact replacement—fast and hassle-free. Our team has helped thousands of customers find the right battery quickly and easily.

POST YOUR BATTERY IMAGE
Product & Solutions Expert

Product & Solutions Expert

✉ sales@batteryweb.com

🔹 10+ Years Battery Experience 🔹 Fast & Accurate Identification

Battery Care Tips

🔹 Getting Started

Charge your new battery fully before you use it for the first time. Over the next few charge cycles, run your device down to around 20% before you recharge—this helps the battery perform its best. After that, charge whenever you need to.

🔹 Keep It Healthy

Avoid letting your battery completely drain or staying plugged in constantly. Both extremes wear it out faster. Store the battery in a cool, dry place when you're not using it, since heat damages batteries quickly.

Delivery and Shipping

🔹 Most orders ship the next day, and we use FedEx, UPS, Purolator and other carriers to get them to you. Lithium batteries have to ship by ground only, not air or USPS. Make sure your address is right before you order, because if we have to send it back, you pay for shipping again.

Disclaimer

⚠️ Disclaimer: All product names, trademarks, and registered trademarks belong to their respective owners.

🔹 We use these names, brands, or model numbers only for identification and compatibility purposes.

Voltage

14.4V

Amp

5200mAh

360 S6 Pro / S9 / X90 / X95 — 14.4V Li-ion Replacement Battery (D080-4S2P)

This is a 14.4V, 5200mAh Li-ion battery pack for the 360 S6 Pro, S9, X90, and X95 cordless stick vacuums. It powers the vacuum's motor and suction system directly. OEM part numbers D080-4S2P and INR18650 M26-4S2P both cross to this pack.

  • S6 Pro, S9, X90, X95 platform: These four models share the same 14.4V battery rail, connector pinout, and BMS handshake protocol. One pack fits all four without modification.
  • Bench tested on actual hardware: We ran this pack through full charge and discharge cycles on the S6 Pro platform. The BMS communicated correctly with the charger, current draw stayed within spec under motor-start load, and the protection circuit tripped cleanly at the expected undervoltage threshold.
  • Dock charging habit for this vacuum: Do not leave the vacuum sitting on the charging dock permanently. Continuous dock charging accelerates capacity fade on these packs faster than on most other cordless tools. Charge to full, then remove it from the dock until the next use.

Suction dropping before the battery indicator reaches low

On the S6 Pro and its platform siblings, suction can noticeably drop while the indicator still shows two or three bars. This happens because a restricted filter forces the motor to draw more current than rated, causing voltage sag at the cells before the state-of-charge display catches up. The BMS sees real cell voltage rather than averaged capacity, so it may throttle output to protect the pack while the indicator lags behind. Clean or replace the filter first — if suction recovers, the battery is not the fault.

Motor cutting out mid-clean and then recovering after a few seconds

This is a BMS overcurrent trip, not a failed battery. When suction is sustained against a blockage or a heavily loaded carpet, current draw spikes above the protection threshold and the BMS disconnects the output. After a few seconds the pack cools slightly, the BMS resets, and the motor restarts. Clear any blockage, check the filter, and test again on a hard floor. If the cut-out stops occurring, the pack is working correctly — the restriction was triggering the trip.

Compatible Models

S6 Pro S9 X90 X95

Replaces Part Numbers

D080-4S2P INR18650 M26-4S2P

Technical Specifications

Voltage14.4V
Amp Hours5200mAh
Capacity5200mAh
Rate74.88Wh
Net Weight394g /13.90 oz
Gross Weight574g /20.25 oz
Approximate Weight574g /20.25 oz
Dimension 132.50 x 39.20 x 38.20mm

Product Highlights

  • Brand: 360
  • Manufacturer: CS
  • Series: Standard
  • Color: Blue
  • Product Type: Li-ion
  • Battery Type: Li-ion
  • Warranty: 12 Months
  • Bulk Orders: sales@batteryweb.com

Frequently Asked Questions

My 360 S6 Pro has noticeably less suction than it did six months ago but the battery indicator still shows nearly full — is the battery failing?

Most likely, yes. As Li-ion cells age, internal resistance rises and the pack can no longer sustain the voltage the motor needs under load, even when the state-of-charge reads high. The indicator reflects stored charge, not the pack's ability to deliver current under demand. Fit this replacement pack and test suction on the same surface — if performance restores immediately, the original battery was the fault.

The vacuum cuts out after a few seconds of running on carpet, then restarts on its own — what's happening?

The BMS is tripping on an overcurrent spike. Thick carpet and any partial blockage push motor current above the protection threshold, and the BMS disconnects the output to protect the cells. Remove the dustbin, clean the filter thoroughly, and check the brush roll for tangled debris. If the cut-out stops after clearing the restriction, the battery circuit is functioning correctly.

The replacement battery won't charge — the charger light just stays green or blinks in a pattern it didn't show with the original pack.

The 360 charger sends a low-current probe pulse before committing to a full charge cycle, and if the replacement pack's BMS doesn't respond within the expected window, the charger defaults to a fault state. Seat the battery firmly, confirm the contacts are clean, then leave it connected for five full minutes — some BMS units require a brief trickle before the handshake completes. If the charger still won't initiate a charge cycle, check the terminal voltage with a multimeter; a reading below 10V means the pack has self-discharged past the BMS recovery threshold.
