Schneide 10 AGS Replacement Battery 4.8V 2000mAh Ni-MH

Schneide 10 AGS / AGS 65 Series — 4.8V Ni-MH Replacement Battery

This is a 4.8V 2000mAh Ni-MH replacement battery for the Schneide cordless vacuum range. It fits the 10 AGS, AGS 65, AGS10, and AGS65 handheld and stick vacuum models. Dimensions are 86.50 × 45.34 × 22.50mm — confirm against your existing pack before ordering.

• AGS series compatibility: The 10 AGS, AGS10, AGS 65, and AGS65 all run the same 4.8V cell configuration with a shared connector footprint. That common voltage rail and pack geometry is why one replacement covers all four model designations without modification.
• Bench tested on actual hardware: We cycled this pack through charge and discharge on the bench. The Ni-MH cells held steady voltage across the discharge curve, and the BMS did not trip under the sustained low-current draw typical of these vacuum motors.
• Dock charging habit on these vacuums: Do not leave the vacuum sitting on the charging dock permanently. Ni-MH cells in this voltage range develop capacity fade significantly faster under continuous trickle charge. Charge to full, then remove the unit from the dock until the next use.

Cordless vacuum losing suction before the battery indicator reaches low

This happens when a partially blocked filter forces the motor to draw more current than rated. The extra load pulls the cell voltage down faster than the indicator circuit tracks. The indicator reads the battery state, not the actual motor load — so it shows charge remaining while suction has already dropped. Clean or replace the filter first, then recharge to a full 4.8V before testing again.

Motor cutting out mid-clean and recovering after a few seconds

This is a BMS overcurrent trip, not a dead battery. When suction is restricted — blocked nozzle, clogged filter, or hair wrap on the brush — motor current spikes and the protection circuit cuts power to prevent cell damage. The pack resets once current drops, which is why the vacuum restarts after a short pause. Clear the blockage completely, then verify the pack is sitting above 4.0V under load before assuming the battery is at fault.
