Wexler E6002 Replacement Battery 3.7V 1700mAh Li-ion

Wexler E6002 — 3.7V Li-ion 1700mAh Replacement Battery

This is a 3.7V Li-ion cell rated at 1700mAh (6.29Wh), cut to fit the Wexler E6002 smartphone. It replaces the original cell when capacity has dropped to the point where the phone no longer lasts through a normal day of calls, messaging, and app use. Physical dimensions are 66.20 × 44.00 × 5.10mm — measure your existing cell before ordering if you are unsure.

• E6002 fitment: The E6002 uses a bare Li-ion pouch cell with no smart connector or authentication handshake — voltage rail and physical size determine fitment. This cell matches both, so the phone's charge IC accepts it without rejection flags.
• Bench tested on actual hardware: We cycled the cell through charge and discharge on a smartphone test rig, confirmed BMS protection triggers correctly at low-voltage cutoff, and verified the charge IC accepted full current without thermal runaway or early termination.
• Fuel gauge recalibration on first use: On first use after installation, run one complete discharge to automatic shutdown, then charge uninterrupted to 100% before resuming normal use. This gives the E6002's fuel gauge IC a clean reference curve against the new cell — skipping this step is why percentage readings jump erratically in the first few days.

Sudden shutdown at 20–30% on the Wexler E6002

This is a voltage cliff, not a capacity fault. Under modem transmission load or screen-on bursts, the cell voltage drops sharply below the threshold the phone's protection circuit tolerates — even if the fuel gauge still shows charge remaining. It happens most often with a new cell because the fuel gauge IC is still calibrated to the old cell's discharge curve. One full discharge-to-shutdown cycle followed by an uninterrupted charge resets the coulomb counter and eliminates most cliff shutdowns. If it persists after two full cycles, check that the battery connector tab is fully seated — a loose contact increases internal resistance and worsens voltage sag under load.

Phone won't power on after the replacement cell sat in storage

Li-ion cells self-discharge during storage, and if voltage dropped below approximately 2.5V per cell, the BMS has locked out the output rail as a protection measure. Plug the phone into a wall charger — not a USB port — and leave it for 20–30 minutes without pressing the power button. The charge IC needs to trickle current into the cell to lift voltage back above the BMS re-enable threshold before the phone will respond. Once the screen shows a charging indicator, a normal charge cycle will bring it back to full capacity.
